Gerbera Harvesting Robot Getting Closer to Reality

By Greenhouse Grower

A gerbera harvesting robot originally developed by the Greenhouse Horticulture Business Unit of Wageningen University & Research (WUR) has improved significantly over the past year, reports Greenhouse Grower. The end-effector (which harvests the gerbera stems) is considerably faster than before, due to changes in the way the gripper descends down the stem. In addition, the robot relies less on 3D visualization, so the processing power needed to harvest the gerberas is shortened.

Here’s how the robot works:

A top view camera detects the flowers that are ripe and need to be harvested.
A robot arm with end effector approaches the stem directly under the flower and descends to the bottom of the plant.
Then the actual harvesting starts. There are roughly two methods for this: picking the stem or cutting the stem. The latter method has been chosen for the gerbera harvesting robot. The main advantage of this method is that the harvesting direction does not matter, which is the case with picking.

To harvest, the robot has to find the exact location of the stem. In the previous prototype, the robot calculated the position and orientation of the entire stem under the flower with the help of camera information and calculated 3D visualisations. This requires a lot of computing power, and thus time.
